- Construction
Double walled in construction Inner made of SS 304 & Ext. GI Powder Coated shade in REGULAR MODEL. Double walled in construction Inner made of SS 304 & Outer made of SS 304 Matt/Buff Finish in GMP MODEL.
- Insulation
The high grade PUFF/Wool Insulation provided in between the wall to minimize the heat loss.
- Controller
The Temp. is being controlled by Microprocessor based PID Temp. & Humidity Controller with Dual Digital Indicator & PT – 100 sensor for Temp & Capitence type sensor for RH%.
- Air Circulation
The air circulation is being performed by motorized blower firmly installed at the back or top of the Unit.
- Cooling Kit
The Cooling Kit includes hermetically sealed compressor, condenser, fan motor etc and are safely placed at the Bottom/Top of the unit . The cooling system is CFC free. Overload protection relay with time delay to switch on the compressor is provided.
- Humidification
The Humidification will be through Steam Injection System. The Stainless Steel Boiler Tank is provided having special refractory type SS Heater. A reservoir tank made of SS with float valve provided for continuous supply of water to Boiler.
- Heater
The Heating provided by U Type SS Air Heater.
- Shelves
The Shelves are Adjustable SS 304 Rod Type shelves provided depending upon selection of size.
- Illumination
The Illumination is provided by LED tube for clear visibility of test.
- Acrylic Door
A fully insulated door with Acrylic view is provided for clear observation of test.
Temp. Accuracy :- Within ± 1°C
Humidity Accuracy :- Within ± 2% RH
Size & Price
| CAT NO. | INNER SIZE (W x D x Ht.) | CAPACITY (LTRS.) | CAPACITY (CFT) | HEATERS RATING | SHELVES |
|---|---|---|---|---|---|
| CIC – 90/91 | 18” x 18” x 28” | 150 | 5.25 | 1.5 k.w. | 2 |
| CIC – 90/91 | 24” x 24” x 24” | 228 | 8.00 | 2.0 k.w. | 2 |
| CIC – 90/91 | 24” x 24” x 36” | 342 | 12 | 2.5 k.w. | 3 |
| CIC – 90/91 | 26” x 26” x 36” | 400 | 14 | 2.5 k.w. | 3 |
| CIC – 90/91 | 30” x 30” x 42” | 623 | 21 | 3.5 k.w. | 4 |
| CIC – 90/91 | 36” x 36” x 40” | 850 | 30 | 4.5 k.w. | 5 |
| CIC – 90/91 | 38” x 38” x 48” | 1040 | 36 | 6.0 k.w. | 6 |
NOTE: Walk in Seed Germinator Available
